Panel Size 15.8″ (diagonal)

Resolution 2560 x 1440 (16:9) QHD

PPI (Pixels Per Inch) 186PPI

LCD Type IPS 60Hz

Active Area 349.6 x 196.7 mm

Contrast Ratio 1200:1

Brightness 220nit (Max.)

Response Time 14ms

Viewing Angle 178° (89°/89°(H)/89°/89°(V) (Typ.)(CR＞10))

Gamut 145% sRGB

Display Color 16.7M (8bit)

Pen Technology Battery-Free EMR

Pen Resolution 5080LPI

Pressure Levels 8192Levels

Accuracy ±0.3mm (Center), ±1mm (Corner)

Reading Height 10mm

Tilt Recognition ±60°

Digital Pen PW517

Input Voltage AC 100-240V, 50/60Hz

Output Voltage 5V 3A

Video Interface Full-Featured USB-C (Compatible with HDMI and DP) / Power USB-C

Press Keys 8 Programmable Press Keys

OS Support

Windows 7 or later, macOS 10.12 or later, Android(USB3.1 DP1.2 or later)

AG Glass

Etched Anti-Glare Glass

Full Lamination

Power Consumption ≤10W

Standby Consumption ≤0.25W

Working Temp. and Humidity 0-40°C, 20-80%

Storage Temp. and Humidity -20°C~60°C, 10-90%

Dimension 436.2 x 247.3 x 10~11.5mm
